The PI3HDX1204-BZHE HDMI Evaluation Board, brought to you by Diodes Incorporated, is a state-of-the-art platform designed to showcase the capabilities of the PI3HDX1204 HDMI signal conditioning repeater IC. This evaluation board is an essential tool for developers and engineers looking to test and integrate HDMI features into their high-definition video applications.

Key Features

• Advanced Signal Conditioning: The board features the PI3HDX1204 IC, which provides active signal conditioning to improve signal integrity for high-speed HDMI signals.
• 4K Support: It is capable of supporting resolutions up to 4K at 30Hz, ensuring compatibility with the latest ultra-high-definition video formats.
• High Bandwidth: With a bandwidth capacity of up to 3.4 Gbps per channel, this board is designed to handle the latest HDMI 1.4 specifications without compromising on performance.
• Easy to Use: The evaluation board is user-friendly and comes with all the necessary connectors and interfaces, making it easy to evaluate the PI3HDX1204 IC's performance.
• Plug and Play: No additional software or drivers are required, offering a true plug-and-play experience for quick and efficient testing.

Applications

The PI3HDX1204-BZHE HDMI Evaluation Board is ideal for a wide range of applications, including:

• High-definition televisions (HDTVs)
• Digital signage and video walls
• Home theater systems
• Professional AV systems
• Gaming consoles
• Video conferencing equipment

Technical Specifications

The evaluation board comes equipped with the following technical specifications:

• Support for HDMI 1.4 high-speed signaling
• 3.4 Gbps bandwidth per channel
• Support for 4K resolution at 30Hz
• Embedded HDCP keys for secure transmission of protected content
• Onboard HDMI connectors for input and output

With the PI3HDX1204-BZHE HDMI Evaluation Board from Diodes Incorporated, you can be assured of a comprehensive and practical evaluation experience that will streamline the development process for your high-definition video projects.
