FDV302P

Part No FDV302P
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 25V 120MA SOT-23
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 25V
Continuous Drain Current at 25°C 120mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.7V, 4.5V
Gate-Source Threshold Voltage 1.5V @ 250μA
Max Gate Charge 0.31nC @ 4.5V
Max Input Capacitance 11pF @ 10V
Maximum Gate-Source Voltage ±8V
Power Dissipation (Max) 350mW (Ta)
Maximum Rds On at Id,Vgs 10 Ohm @ 200mA, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 016219-FDV302P
Family Name FDV302P
Introduction Date October 30, 1997
ECCN EAR99
Country of Origin Ireland, Israel, Philippines
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial, Power Management
Ultra Librarian 3D Model Ultra Librarian FDV302P CAD Model

Description

FDV302P from Fairchild/ON Semiconductor is an RF MOSFET positioned for designers who need a compact transistor solution in signal handling, switching, and RF-oriented circuit paths. It is commonly evaluated for use in portable electronics, communication modules, control stages, and supporting analog or high-frequency designs where board space, efficiency, and predictable sourcing matter. Because this device sits in the RF MOSFET category, engineers may consider it for front-end support functions, interface switching, or other transistor roles that require careful datasheet review before design-in. The current lifecycle status is information not available, so teams should assess supply continuity and approved alternates before committing it to new production programs. RoHS compliance information is also not available in the provided data and should be confirmed through the latest manufacturer documentation or authorized distribution sources. For procurement and compliance-sensitive applications, verified manufacturer records remain essential before qualification.
