IRFS614B

Part No IRFS614B
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description N-CHANNEL POWER MOSFET
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr Fairchild/ON Semiconductor
Package Bulk
Product Status Active
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 250 V
Current - Continuous Drain (Id) @ 25°C 2.8A (Tj)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 2Ohm @ 1.4A, 10V
Vgs(th) (Max) @ Id 4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 10.5 nC @ 10 V
Vgs (Max) ±30V
Input Capacitance (Ciss) (Max) @ Vds 275 pF @ 25 V
Power Dissipation (Max) 22W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Supplier Device Package TO-220F
Package / Case TO-220-3 Full Pack
Standard Package 1,664 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 605330-IRFS614B

Description

The 605330-IRFS614B is a single N-channel MOSFET transistor designed for use in discrete semiconductor products. It is part of the Fairchild/ON Semiconductor series and comes in a bulk package with a standard package of 1,664 pieces. The transistor has a drain to source voltage (Vdss) of 250 V and a continuous drain current (Id) of 2.8 A. The maximum on-resistance (Rds On) is 2 Ohm at an Id of 1.4 A and Vgs of 10 V. The gate threshold voltage (Vgs(th)) is 4 V at an Id of 250 µA. The transistor has a power dissipation of 22 W and can operate in a temperature range of -55°C to 150°C. It is an active product with a drive voltage of 10 V. The 605330-IRFS614B is commonly used in applications that require high voltage and low on-resistance, such as power supplies and motor control circuits.
