Same model may have multiple batches, images only for reference.
MJE801STU Fairchild/ON Semiconductor
Same model may have multiple batches, images only for reference.

MJE801STU

Part No MJE801STU
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description Trans Darlington NPN 60V 4A 40000mW 3-Pin(3+Tab) TO-126 Rail / TRANS NPN DARL 60V 4A TO126
Datasheet
MJE801STU Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube
Part Status Obsolete(EOL)
Transistor Type NPN - Darlington
Current - Collector (Ic) (Maximum) 4A
Voltage - Collector Emitter Breakdown (Maximum) 60V
Vce Saturation (Maximum) @ Ib, Ic 2.8V @ 40mA, 2A
Current - Collector Cutoff (Maximum) 100μA
DC Current Gain (hFE) (Minimum) @ Ic, Vce 750 @ 2A, 3V
Power - Max 40W
Operating Temperature Range 150°C (TJ)
Mounting Style Through Hole
Package TO-225AA, TO-126-3
Manufacturer Package TO-126
Win Source Part Number 788855-MJE801STU
Popularity Medium
Supply and Demand Status Limited
Family Name MJE801
Introduction Date April 09, 1999
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian MJE801STU CAD Model

Description

The Fairchild/ON Semiconductor MJE801STU is an NPN-Darlington transistor with a TO-225AA, TO-126-3 package. It has a maximum power of 40W and a collector current of 4A.

  • Package: TO-225AA, TO-126-3
  • Maximum Power: 40W
  • Collector Current: 4A
  • Collector-Emitter Breakdown Voltage: 60V
  • Vce saturation: 2.8V @ 40mA, 2A
  • DC Current Gain: 750 @ 2A, 3V
  • Compliance: Halogen-Free
  • Status: Obsolete, Limited Supply and Demand
