BSS138WH6327XTSA1 Infineon Technologies BSS138WH6327XTSA1 Real Image
BSS138WH6327XTSA1 Infineon Technologies BSS138WH6327XTSA1 Real Image
Same model may have multiple batches, images only for reference.

BSS138WH6327XTSA1

Part No BSS138WH6327XTSA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 280MA SOT-323
Datasheet
BSS138WH6327XTSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 280mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 1.4V @ 26μA
Max Gate Charge 1.5nC @ 10V
Max Input Capacitance 43pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 500mW (Ta)
Maximum Rds On at Id,Vgs 3.5 Ohm @ 200mA, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-SOT323-3
Dimension SC-70, SOT-323
Win Source Part Number 1024501-BSS138WH6327XTSA1
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian BSS138WH6327XTSA1 CAD Model

Description

The Infineon Technologies MOSFET is a high-performance N-channel power transistor that can handle a maximum power dissipation of 500mW (Ta).

  • Channel Type: N-channel
  • Power Dissipation: 500mW (Ta)
  • Package: PG-SOT323-3
  • Drain-Source Breakdown Voltage: 60V
  • Continuous Drain Current: 280mA (Ta)
  • Gate-Source Threshold Voltage: 1.4V @ 26μA
  • Category: Discrete semiconductor products
  • Maximum Rds On @ Id,Vgs: 3.5 Ohm @ 200mA, 10V
