BSZ100N06LS3 G Real Image BSZ100N06LS3 G Real Image1 BSZ100N06LS3 G Real Image2 BSZ100N06LS3 G Real Image3 BSZ100N06LS3 G Real Image4
Same model may have multiple batches, images only for reference.
BSZ100N06LS3 G Real Image BSZ100N06LS3 G Real Image1 BSZ100N06LS3 G Real Image2 BSZ100N06LS3 G Real Image3 BSZ100N06LS3 G Real Image4
BSZ100N06LS3 G Real Image BSZ100N06LS3 G Real Image1 BSZ100N06LS3 G Real Image2 BSZ100N06LS3 G Real Image3 BSZ100N06LS3 G Real Image4
Same model may have multiple batches, images only for reference.

BSZ100N06LS3 G

Part No BSZ100N06LS3 G
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 20A TSDSON-8
Datasheet
BSZ100N06LS3 G Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Series OptiMOS
Packaging Reel package
Channel Type Type N
Technology MOSFET
Drain Source Voltage 60V
Current - Continuous Drain (Id) @ 25°C 11A (Ta), 20A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Vgs(th) (Maximum) @ Id 2.2V @ 23μA
Gate Charge (Qg) (Maximum) @ Vgs 45nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 3500pF @ 30V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 2.1W (Ta), 50W (Tc)
Rds On (Maximum) @ Id, Vgs 10 mOhm @ 20A, 10V
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting SMD
Manufacturer Package PG-TSDSON-8
Package 8-PowerVDFN
Win Source Part Number 770442-BSZ100N06LS3 G
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BSZ100N06LS3 G CAD Model

Description

The BSZ100N06LS3 G from Infineon Technologies is an N-Channel MOSFET.

  • Drain-Source Voltage: 60V
  • Continuous Drain Current @ 25°C: 11A
  • Gate-Source Threshold Voltage: 2.2V @ 23μA
  • Maximum Gate Charge: 45nC @ 10V
  • Input Capacitance: 3500pF @ 30V
  • Package: PG-TSDSON-8
  • Power Dissipation (Ta): 2.1W
  • Power Dissipation (Tc): 50W
  • Rds On (Maximum) @ Id,Vgs: 10 mOhm @ 20A, 10V
  • Category: Discrete Semiconductor Products
  • Popularity: Medium
  • Supply and Demand Status: Limited
