IRF2804STRLPBF

Name: IRF2804STRLPBF
Brand: Infineon Technologies
SKU: 159434
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	IRF2804STRLPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 40V 75A D2PAK
Datasheet	IRF2804STRLPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	40V
Continuous Drain Current at 25°C	75A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4V @ 250μA
Max Gate Charge	240nC @ 10V
Max Input Capacitance	6450pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	300W (Tc)
Maximum Rds On at Id,Vgs	2 mOhm @ 75A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	D2PAK
Dimension	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number	129107-IRF2804STRLPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	IRF2804S
Introduction Date	August 25, 2005
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Ultra Librarian 3D Model	Ultra Librarian IRF2804STRLPBF CAD Model

Description

The Infineon Technologies IRF2804STRLPBF is a N-Channel MOSFET that is commonly used in power management.

Maximum Power Dissipation: 300W (Tc)
Drain-Source Breakdown Voltage: 40V
Continuous Drain Current: 75A (Tc) @ 25°C
Gate-Source Threshold Voltage: 4V @ 250μA
Maximum Rds On: 2 mOhm @ 75A, 10V
Supply and Demand Status: balanced
