IRFR540ZPBF Infineon Technologies IRFR540ZPBF Real Image IRFR540ZPBF label picture
Same model may have multiple batches, images only for reference.
IRFR540ZPBF Infineon Technologies IRFR540ZPBF Real Image IRFR540ZPBF label picture
IRFR540ZPBF Infineon Technologies IRFR540ZPBF Real Image IRFR540ZPBF label picture
Same model may have multiple batches, images only for reference.

IRFR540ZPBF

Part No IRFR540ZPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 35A DPAK
Datasheet
IRFR540ZPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Not For New Designs
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 35A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 50μA
Max Gate Charge 59nC @ 10V
Max Input Capacitance 1690pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 91W (Tc)
Maximum Rds On at Id,Vgs 28.5 mOhm @ 21A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 017692-IRFR540ZPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRFR540ZPBF CAD Model

Description

The Infineon Technologies 017692-IRFR540ZPBF is an N-channel MOSFET with a drain-source breakdown voltage of 100V and continuous drain current of 35A (Tc) @ 25°C.

  • Drain-Source Breakdown Voltage: 100V
  • Continuous Drain Current: 35A (Tc) @ 25°C
  • Power Dissipation: 91W (Tc)
  • Maximum Rds on at Id,Vgs: 28.5 mOhm @ 21A, 10V
  • Gate-Source Threshold Voltage: 4V @ 50μA
  • Maximum Gate Charge: 59nC @ 10V
  • Popularity Rating: Medium
  • Supply and Demand Status: Balanced
