IRLML5203TRPBF

Name: IRLML5203TRPBF
Brand: Infineon Technologies
SKU: 161512
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	IRLML5203TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 30V 3A SOT-23
Datasheet	IRLML5203TRPBF Datasheet
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	3A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	2.5V @ 250μA
Max Gate Charge	14nC @ 10V
Max Input Capacitance	510pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	1.25W (Ta)
Maximum Rds On at Id,Vgs	98 mOhm @ 3A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	Micro3/SOT-23
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	017770-IRLML5203TRPBF
Family Name	IRLML5203
Introduction Date	November 08, 2004
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Power Management, Consumer Electronics, Portable Devices, Industrial
Ultra Librarian 3D Model	Ultra Librarian IRLML5203TRPBF CAD Model

Alternative Products

Description

The Infineon Technologies 017770-IRLML5203TRPBF is a P-Channel MOSFET electronic component.

Mounting: SMD (Surface Mount Device)
Package: Reel - TR
Drain-Source Breakdown Voltage: 30V
Maximum Power Dissipation: 1.25W (Ta)
Maximum Rds On @ Id,Vgs: 98 mOhm @ 3A, 10V
Gate Charge: 14nC @ 10V
Suitable for: Power management, consumer electronics, portable devices, and industrial applications
Supply and Demand Status: Balanced
