Product Overview: LTC1563-2CGN#PBF

The LTC1563-2CGN#PBF from Linear Technology is a highly integrated active RC filter that is designed to provide a precise and stable filtering solution for a wide range of applications. This component is part of the LTC1563 series and comes in a compact 16-lead SSOP package, offering a space-efficient design for modern electronic devices.

Key Features

• Active RC Filter: The LTC1563-2CGN#PBF is based on an active RC filter architecture, ensuring high linearity and low noise performance. This makes it ideal for applications requiring a clean and accurate signal processing.
• Lowpass Filter with Selectable Cutoff Frequencies: This component features an easy-to-use lowpass filter with a programmable cutoff frequency. The cutoff can be set by external resistors, providing design flexibility and ease of tuning for specific applications.
• High Order Filter: The device implements a 4th-order filter response, which provides superior stopband attenuation and a sharp roll-off. This characteristic is particularly useful for applications that demand a high degree of signal purity and separation.
• Single Supply Operation: Operating from a single 5V supply, the LTC1563-2CGN#PBF simplifies power supply design and is compatible with a variety of digital systems.
• Low THD: With a Total Harmonic Distortion (THD) of typically -75dB, the filter maintains signal fidelity, making it suitable for high-quality audio applications.
• Unity Gain Stable: The filter is designed to be unity gain stable, requiring no external compensation, which reduces external component count and complexity.

Applications

The LTC1563-2CGN#PBF is versatile and can be used in a multitude of applications, including:

• Anti-aliasing filters for data acquisition systems
• Audio processing equipment
• Signal conditioning in communication systems
• ADC/DAC filtering
• Industrial control systems
• Medical electronics

This product from Linear Technology is engineered to address the needs of designers who require a reliable and easy-to-use filtering solution. Its combination of features and performance makes it an excellent choice for high-precision electronic designs.
