MAX323CSA+

Name: MAX323CSA+
Brand: Maxim Integrated
SKU: 210696
Availability: InStock
Rating: 5 (722 reviews)

Part No	MAX323CSA+
Manufacturer	Maxim Integrated
Catalog	Interface - Analog Switches, Multiplexers, Demultiplexers
Description	IC SWITCH DUAL SPST 8SOIC
Datasheet	MAX323CSA+ Datasheet
Sample
Rohs State	Need to verify
ECAD Module

	New List Existing List This product has been added to your List. List Name:

Shipping Information

Shipped from	HK warehouse
Expected Shipping Date	Ship today if order in (HKT)
Supplier Lead-Time	Call for availability
Estimate shipping fee	Enter your destination to get a shipping estimate Estimate Shipping Fee

Pricing & Ordering $10.4057

Quantity

Unit Price

Ext. Price

$14.5530

$58.212

$11.9410

$107.469

13+

$11.5680

$150.384

18+

$11.1940

$201.492

24+

$10.8210

$259.704

31+

$9.7020

$300.762

* The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Availability: 2,526 pieces

MOQ: 4 pcs

Order Increment : 1 pcs

Qty:

*Need More Quantity? *Request a Bulk Quantity Quotation?

Products specifications

Category	Integrated Circuits(ICs)
Family	Interface - Analog Switches, Multiplexers, Demultiplexers
Manufacturer	Maxim Integrated
Packaging	Tube
Switch Circuit	SPST - NO
Number of Circuits	2
On-State Resistance (Max)	60 Ohm
Channel-to-Channel Matching (ΔRon)	800 mOhm
Voltage - Supply, Single (V+)	2.7 V ~ 16 V
Switch Time (Ton, Toff) (Max)	150ns, 100ns
Charge Injection	1pC
Channel Capacitance (CS(off), CD(off))	9pF, 9pF
Current - Leakage (IS(off)) (Max)	100pA
Crosstalk	-85dB @ 1MHz
Operating Temperature Range	0°C ~ 70°C (TA)
Package	8-SOIC (0.154", 3.90mm Width)
Manufacturer Device Package	8-SOIC
Win Source Part Number	003012-MAX323CSA+

Description

MAX323CSA+ - Maxim Integrated

The MAX323CSA+ is a precision, dual-voltage, SPST (Single-Pole Single-Throw) analog switch from Maxim Integrated, designed to provide superior switching performance for a variety of applications. This component is part of Maxim's commitment to delivering high-quality, reliable integrated circuits that meet the demanding requirements of modern electronic systems.

Key Features

Low Voltage Operation: The MAX323CSA+ operates at a single +2V to +12V supply or at ±2V to ±6V dual supplies, making it versatile for both digital and analog signal switching.
Low On-Resistance: It features a low on-resistance (R_ON) of 100Ω max, ensuring minimal signal distortion and power loss during operation.
High Accuracy: The device offers high accuracy with a guaranteed R_ON match between channels of 5Ω max and R_ON flatness of 4Ω max, which is critical for precision applications.
Fast Switching Speeds: The switch transition times (t_ON/t_OFF) are exceptionally fast, typically 175ns/145ns, thus suitable for high-speed signal routing.
Low Power Consumption: With a low power consumption, the MAX323CSA+ is ideal for power-sensitive applications, offering a quiescent current of only 1µA max.
ESD Protection: It includes enhanced ESD protection, with ±2000V Human Body Model (HBM) protection on the switch inputs, minimizing the risk of damage during handling and operation.

Applications

The MAX323CSA+ is well-suited for a wide range of applications including:

Sample-and-hold circuits
Audio signal routing
Test equipment
Analog and digital multiplexing
Battery-powered systems

Package and Quality

The device is offered in a compact 8-pin SOIC package, providing a space-saving solution for PCB layouts. It is also fully specified over the extended industrial temperature range (-40°C to +85°C), ensuring reliable performance in challenging environments. Maxim Integrated's commitment to quality is reflected in the MAX323CSA+'s design and manufacturing processes, which adhere to rigorous standards to ensure high durability and performance over the product's lifespan.
