Microchip Technology KSZ8563RNXV Overview

The KSZ8563RNXV is a highly integrated Ethernet switch from Microchip Technology, designed to enable network connectivity and management in a wide range of applications. Its robust feature set makes it ideal for use in automotive, industrial, and commercial products that require reliable data communication.

Key Features

• 3-Port Ethernet Switch: The KSZ8563RNXV contains two 10/100BASE-TX ports and one 100BASE-FX fiber port, providing versatility in connection types and facilitating mixed-media networks.
• Energy Efficient: With support for Energy Efficient Ethernet (IEEE 802.3az), the device can reduce power consumption during periods of low data activity, making it suitable for energy-conscious applications.
• Advanced Switching Capabilities: The switch includes features like Quality of Service (QoS), VLAN support, and IGMP snooping, enabling efficient management of data traffic and multicast streams.
• Robust Security: Security features include MAC address filtering, network access control, and port-based authentication, ensuring secure network access and data integrity.
• Industrial Temperature Range: The KSZ8563RNXV operates over an extended temperature range (-40°C to +85°C), ensuring reliability in harsh environments.
• Compact Form Factor: The small footprint of the device is beneficial for space-constrained applications, allowing for integration into a variety of designs without significant space requirements.

Applications

The versatility of the KSZ8563RNXV makes it an excellent choice for a multitude of applications, including:

• Automotive networking systems
• Industrial control and automation
• Building automation and security systems
• Embedded systems requiring network connectivity

Product Specifications

The KSZ8563RNXV is available in a 48-pin QFN package and is designed for easy integration into existing and new designs. It supports various host interfaces such as SPI and I²C, allowing for flexible system integration and connectivity options.

As a product of Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions, the KSZ8563RNXV is backed by a comprehensive ecosystem of development tools and software, ensuring a smooth design process and rapid deployment into the market.
