Microchip Technology LAN9514-JZX Product Overview

The LAN9514-JZX is an advanced, high-performance USB 2.0 multi-port hub with an integrated 10/100 Ethernet controller. Manufactured by Microchip Technology, this versatile and reliable component is designed to support a wide range of applications that require both Ethernet and USB connectivity.

Key Features:

• High-Speed USB 2.0 Interface: The LAN9514-JZX features a high-speed USB 2.0 interface that supports up to 480 Mbps data transfer rates, making it ideal for bandwidth-intensive applications.
• Integrated Ethernet Controller: With its built-in 10/100 Ethernet controller, this product provides a fast and efficient network connection for embedded systems.
• Multiple USB Ports: The device includes four downstream USB ports, allowing for the simultaneous connection of multiple USB devices.
• PHY Technology: The product incorporates industry-standard Ethernet PHY technology, ensuring compatibility and reliable performance across different network environments.
• Advanced Power Management: The LAN9514-JZX supports dynamic power management, reducing power consumption during periods of low activity.
• Compact Form Factor: Its small package design makes it suitable for space-constrained applications.

Applications:

The LAN9514-JZX is ideal for a variety of applications, including:

• Embedded Systems
• Networking Equipment
• Industrial Automation
• Home Entertainment Systems
• Set-Top Boxes
• Docking Stations

Technical Specifications:

For detailed technical specifications, designers and engineers should refer to the official datasheet provided by Microchip Technology. The datasheet includes comprehensive information on the LAN9514-JZX's electrical characteristics, pin configurations, timing diagrams, and application circuits.

Quality and Reliability:

Microchip Technology is known for its commitment to quality and reliability. The LAN9514-JZX is built to meet high standards, ensuring stable operation and long service life in a variety of conditions and applications.
