PSMN3R0-60PS,127 Real Image PSMN3R0-60PS,127 label picture
Same model may have multiple batches, images only for reference.
PSMN3R0-60PS,127 Real Image PSMN3R0-60PS,127 label picture
PSMN3R0-60PS,127 Real Image PSMN3R0-60PS,127 label picture
Same model may have multiple batches, images only for reference.

PSMN3R0-60PS,127

Part No PSMN3R0-60PS,127
Manufacturer Nexperia USA Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 100A TO220AB
Datasheet
PSMN3R0-60PS,127 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr Nexperia USA Inc.
Package Tube
Product Status Active
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 60 V
Current - Continuous Drain (Id) @ 25°C 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 3mOhm @ 25A, 10V
Vgs(th) (Max) @ Id 4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs 130 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 8079 pF @ 30 V
Power Dissipation (Max) 306W (Tc)
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Through Hole
Supplier Device Package TO-220AB
Package / Case TO-220-3
Base Product Number PSMN3R0
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 748383-PSMN3R0-60PS,127
Ultra Librarian 3D Model Ultra Librarian PSMN3R0-60PS,127 CAD Model

Description

The PSMN3R0-60PS,127 is an N-channel MOSFET transistor designed for high power applications.

  • Drain-to-Source Voltage (Vdss): 60V
  • Continuous Drain Current (Id): 100A @ 25°C
  • On-Resistance: 3mOhm @ 25A, 10V
  • Gate Charge (Qg): 130nC @ 10V
  • Package: TO-220AB
  • Mounting: Through-hole
  • Maximum Power Dissipation: 306W
  • Operating Temperature: -55°C to 175°C
  • Manufacturer: Nexperia USA Inc.
