Products specifications Report Issue?

Reference Date Code 2016+
Reference case SOT343
Manufacturer NXP
Manufacturer Homepage www.nxp.com
Win Source Part Number 717927-BF998WR
Family Name BF998
Introduction Date April 25, 1995
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BF998WR CAD Model

Description

The NXP BF998WR is a high-performance silicon MOSFET (Metal-Oxide-Semiconductor Field-Effect Transistor) designed for RF (Radio Frequency) applications. This device is particularly well-suited for use in VHF and UHF circuits, including amplifiers, mixers, and oscillators. With its low-noise figure and high gain, the BF998WR is an excellent choice for designers seeking to enhance the performance of their RF circuitry.

Key Features

  • Dual-Gate MOSFET: The BF998WR features a dual-gate structure that allows for better control and flexibility in RF applications.
  • Frequency Range: It operates effectively within the VHF and UHF frequency range, making it versatile for a wide array of RF applications.
  • Low Noise Figure: With its low noise figure, the BF998WR ensures a clear signal, which is critical for high-quality RF performance.
  • High Gain: The device provides high gain, which can be advantageous when designing amplifiers that require strong signal amplification.
  • Surface-Mount Package: The BF998WR comes in a compact SOT-343R surface-mount package, which is suitable for space-constrained applications.

Applications

  • Telecommunication systems
  • RF amplifiers and mixers
  • TV tuners
  • Professional radios
  • High-frequency oscillators

Technical Specifications

Parameter Value Drain-Source Voltage (V<sub>DS) 12 V Gate-Source Voltage (V<sub>GS) ± 8 V Drain Current (I<sub>D) 30 mA Power Dissipation (P<sub>D) 330 mW Noise Figure 1.2 dB Gain 21 dB

The NXP BF998WR is renowned for its reliability and performance, making it a preferred choice for professionals in the field of RF electronics. Its robust design and advanced features ensure it delivers consistent performance, even in demanding environments.
