ON Semiconductor MPSW13RLRA NPN Transistor

The MPSW13RLRA is a robust bipolar NPN transistor designed by ON Semiconductor, a company renowned for its innovative and reliable semiconductor solutions. This particular component is engineered to handle moderate power amplification and switching applications, making it a versatile choice for a wide range of electronic circuits.

With a collector-emitter voltage (VCEO) of 30V and a collector current (IC) capability of up to 1A, the MPSW13RLRA can manage a considerable amount of power for its size. Its power dissipation (PD) is rated at 1.5W, which ensures that the device can sustain a significant thermal load before reaching its maximum operating temperature.

The transistor features a DC current gain (hFE) range of 40 to 180, which means that it can amplify a small input current into a much larger output current, making it ideal for driving loads in a circuit. Its high gain also makes it suitable for audio amplification, signal processing, and other applications that require a strong and stable performance.

Constructed with ON Semiconductor's high-quality materials, the MPSW13RLRA offers excellent reliability. It is housed in a TO-92 package, which is a widely used and easily mountable package type. This makes the MPSW13RLRA a convenient choice for both prototyping and mass production.

For ease of use, the MPSW13RLRA features straightforward pin configuration with the emitter, base, and collector leads clearly identified, allowing for simple integration into circuit designs. It is also characterized by a low saturation voltage, which minimizes voltage losses and improves overall efficiency in switching applications.

As an environmentally conscious product, the MPSW13RLRA is compliant with the RoHS (Restriction of Hazardous Substances) directive, which restricts the use of certain hazardous materials in electronic equipment. This ensures that the product is not only safe for consumers but also has a reduced environmental impact.

In summary, the MPSW13RLRA from ON Semiconductor is a reliable and efficient choice for designers and engineers looking for a high-performance NPN transistor for their power amplification and switching needs. Its robust construction, high current handling, and gain characteristics make it a valuable component in a wide array of electronic applications.
