The NTD20P06LT4G is a high-performance P-Channel Power MOSFET brought to you by ON Semiconductor, a trusted leader in power management and signal conditioning components. This MOSFET is designed to meet the rigorous demands of a wide range of electronic applications, providing efficient power management with low on-state resistance and high switching performance.

Key Features

• Device Type: Power MOSFET
• Channel Type: P-Channel
• Drain-to-Source Voltage (VDSS): 60V
• Continuous Drain Current (ID): 20A
• Power Dissipation (PD): 48W
• On-State Resistance (RDS(on)): 47 mΩ at VGS = 10V
• Gate Charge (Qg): 31 nC (typical)
• Package: DPAK (TO-252)
• RoHS: Compliant

Applications

The NTD20P06LT4G is ideal for a variety of applications that require efficient power control. It is commonly used in:

• Power supply circuits
• DC/DC converters
• Motor drives
• Battery management systems
• Load switch applications
• Power management for consumer electronics

Product Advantages

This MOSFET features advanced technology that provides several advantages over traditional MOSFETs. The low on-state resistance minimizes losses during operation, enhancing overall efficiency. The device is also characterized by fast switching speeds, which makes it suitable for high-frequency applications. Additionally, the NTD20P06LT4G is designed to withstand high energy pulses in the avalanche and commutation modes, ensuring reliability and robustness in challenging conditions.

Quality and Environmental Compliance

ON Semiconductor is committed to environmental stewardship and the NTD20P06LT4G is no exception. The product is fully RoHS compliant, meaning it is free from hazardous substances commonly found in electronic components. This commitment ensures that the MOSFET not only meets the regulatory requirements but also supports the global effort to reduce the environmental impact of electronic waste.
