The ON Semiconductor TIP30 is a versatile and reliable power transistor that is designed to meet a wide range of application requirements. This PNP epitaxial silicon transistor is primarily used for amplification and switching purposes across various electronic circuits. It is widely appreciated for its high power dissipation and low saturation voltage, making it an excellent choice for audio amplifiers, power regulators, and switching applications that require moderate power handling capabilities.

Key Features

• Voltage Capabilities: The TIP30 boasts a collector-emitter voltage (VCEO) of -40V, ensuring it can handle a significant voltage without breakdown.
• Current Handling: With a continuous collector current (IC) of -1A, it can drive moderate loads efficiently.
• Power Dissipation: A power dissipation of 40W allows the TIP30 to manage a substantial amount of energy without overheating.
• High Gain Bandwidth Product: It features a transition frequency (fT) of 3MHz, which is suitable for high-speed switching applications.
• Complementary NPN Type: The TIP30 is complemented by the TIP29 series, which provides designers with flexibility in creating push-pull configurations.

Applications

The TIP30 is commonly used in a variety of applications, including:

• Linear amplification and switching
• Audio power amplifiers
• Power regulators and converters
• Driver stages in high-fidelity amplifiers and audio equipment
• DC-DC converters

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the TIP30 is no exception. It is manufactured to the highest standards to ensure consistent performance and reliability. Each unit undergoes rigorous testing to guarantee it meets the specified parameters and can withstand the demands of various operating conditions.

Environmental Compliance

The TIP30 transistor is compliant with RoHS (Restriction of Hazardous Substances), reflecting ON Semiconductor's dedication to environmental responsibility. This compliance ensures that the use of certain hazardous materials in the manufacturing of the TIP30 is restricted, making it a safer choice for both consumers and the environment.
