RT9164APG Richtek USA Inc. RT9164APG Real Image
Same model may have multiple batches, images only for reference.
RT9164APG Richtek USA Inc. RT9164APG Real Image
RT9164APG Richtek USA Inc. RT9164APG Real Image
Same model may have multiple batches, images only for reference.

RT9164APG

Part No RT9164APG
Manufacturer Richtek USA Inc.
Catalog PMIC - Voltage Regulators - Linear
Description IC REG
Datasheet
RT9164APG Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - Linear
Mfr Richtek USA Inc.
Package Bulk
Product Status Obsolete
Output Configuration Positive
Output Type Adjustable
Number of Regulators 1
Voltage - Input (Max) 14V
Voltage - Output (Min/Fixed) 1.256V
Voltage - Output (Max) 13.6V
Voltage Dropout (Max) 1.4V @ 1A
Current - Output 1A
Current - Quiescent (Iq) 10 mA
PSRR 72dB (120Hz)
Control Features Current Limit
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case TO-261-4, TO-261AA
Supplier Device Package SOT-223
Standard Package 1 pcs
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 300891-RT9164APG
Ultra Librarian 3D Model Ultra Librarian RT9164APG CAD Model

Description

The RT9164APG is a versatile voltage regulator designed for power management applications.

  • Output Voltage: Adjustable
  • Maximum Output Current: 1A
  • Input Voltage Range: 14V
  • Control: Current limit control
  • Protection: Against over current and over temperature conditions
  • Package: TO-261-4, TO-261AA
  • Installation: Surface mount
  • Operating Temperature Range: -40°C to 125°C
  • Status: Obsolete
  • Manufacturer: Richtek USA Inc.
