2SA1295 Sanken 2SA1295 real image21462 2SA1295 real image
Same model may have multiple batches, images only for reference.
2SA1295 Sanken 2SA1295 real image21462 2SA1295 real image
2SA1295 Sanken 2SA1295 real image21462 2SA1295 real image
Same model may have multiple batches, images only for reference.

2SA1295

Part No 2SA1295
Manufacturer Sanken
Catalog Transistors (BJT) - Single
Description TRANS PNP 230V 17A MT200
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Sanken
Packaging Bulk
Transistor Type PNP
Current - Collector (Ic) (Maximum) 17A
Voltage - Collector Emitter Breakdown (Maximum) 230V
Vce Saturation (Maximum) @ Ib, Ic 2V @ 500mA, 5A
Current - Collector Cutoff (Maximum) 100μA (ICBO)
DC Current Gain (hFE) (Minimum) @ Ic, Vce 50 @ 5A, 4V
Power - Max 200W
Frequency - Transition 35MHz
Operating Temperature Range 150°C (TJ)
Mounting Style Through Hole
Package 3-ESIP
Manufacturer Package MT-200
Win Source Part Number 762353-2SA1295
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Audio, Industrial
Family Name 2SA1295
Introduction Date December 01, 1990
ECCN EAR99
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian 2SA1295 CAD Model

Description

The 2SA1295 is a PNP transistor manufactured by Sanken.

  • Maximum Power: 200W
  • Frequency Transition: 35MHz
  • Maximum Collector-Emitter Breakdown Voltage: 230V
  • Collector Cutoff Current: 100μA
