9CRA0848P8G001

Part No 9CRA0848P8G001
Manufacturer Sanyo Denki America Inc.
Catalog Fans, Thermal Management
Description FAN AXIAL DUAL 80X80MM 48VDC / Fan Tubeaxial (Dual) 48VDC Square - 80mm L x 80mm H Ball 158.9 CFM (4.45m³/min) 4 Wire Leads per Fan
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Fans, Thermal Management - Fans - DC Brushless Fans (BLDC)
Mfr Sanyo Denki America Inc.
Series San Ace 80
Package Box
Voltage - Rated 48VDC
Size / Dimension Square - 80mm L x 80mm H
Width 80.00mm
Air Flow 158.9 CFM (4.45m³/min)
Static Pressure 4.620 in H2O (1150.8 Pa)
Bearing Type Ball
Fan Type Tubeaxial (Dual)
Features Counter-Rotating, Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
Noise 76.0dB(A)
Power (Watts) 63.4 W
RPM 12000 Front, 11300 Rear
Termination 4 Wire Leads per Fan
Temperature Range - Operating -4 ~ 158°F (-20 ~ 70°C)
Approval Agency cURus, TUV
Weight 0.993 lb (450.42 g)
Current Rating (Amps) 1.32A
Voltage Range 40.8 ~ 55.2VDC
Material - Frame Plastic
Material - Blade Plastic
Lifetime @ Temp. 40000 Hrs @ 60°C
Base Product Number 9CRA0848
Standard Package 12
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8414.59.6590
Win Source Part Number 1349412-9CRA0848P8G001
Ultra Librarian 3D Model Ultra Librarian 9CRA0848P8G001 CAD Model

Description

The San Ace 80 DC brushless fan from Sanyo Denki America Inc is a high-quality fan designed for thermal management.

  • Manufacturer: Sanyo Denki America Inc
  • Product: San Ace 80 DC Brushless Fan
  • Voltage Rating: 48VDC
  • Power Rating: 63.4 W
  • Size: 80mm L x 80mm H
  • Fan Shape: Square
  • Air Flow: 158.9 CFM (4.45m³/min)
  • Static Pressure: 4.620 in H2O (1150.8 Pa)
  • Bearing Type: Ball
  • Product Status: Active
