Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 650V
Id - Continuous Drain Current 20A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 154mOhm at 10A, 10V
Gate Source Voltage(th) (Maximum) at Id 4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 41.5nC at 10V
Gate Source Voltage (Maximum) ±25V
Input Capacitance (Ciss) (Maximum) at Vds 1790pF at 100V
Power Dissipation (Maximum) 150W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style SMD
Supplier Device Package PowerFlat (8x8) HV
Manufacturer Package 8-PowerVDFN
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 712355-STL33N65M2
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian STL33N65M2 CAD Model

Description

The STL33N65M2 is a high-performance, N-channel Power MOSFET produced by the renowned semiconductor manufacturer, STMicroelectronics. This power MOSFET is designed to meet the stringent requirements of modern electronic applications, offering a perfect blend of efficiency, reliability, and energy-saving capabilities.

Key Features

  • Advanced Technology: The STL33N65M2 is built on STMicroelectronics' advanced MDmesh™ M2 technology, which provides a low on-resistance and reduced gate charge, enhancing the overall efficiency of the device.
  • High Voltage Capability: With a maximum V<sub>DS of 650V, this MOSFET is suitable for high voltage applications, ensuring safe operation under elevated voltage conditions.
  • Low On-Resistance: Offering an extremely low typical on-resistance of just 190 mΩ, the STL33N65M2 minimizes conduction losses, making it ideal for high-efficiency power supplies and converters.
  • High Current Handling: The device is capable of handling continuous drain currents up to 33A, making it suitable for high-power applications.
  • Enhanced Thermal Performance: The STL33N65M2 comes in a TO-247 long leads package, which provides excellent thermal performance and simplifies the heat sinking process.

Applications

The STL33N65M2 is designed for a variety of applications, including:

  • Switching power supplies
  • Power converters and inverters
  • Motor control systems
  • LED lighting solutions
  • High-performance computing

Conclusion

STMicroelectronics' STL33N65M2 Power MOSFET is a testament to the company's commitment to providing advanced semiconductor solutions. With its robust design, high voltage and current handling capabilities, and the efficiency provided by MDmesh™ M2 technology, this MOSFET is an excellent choice for engineers and designers looking to optimize their high-power electronic systems. Whether for industrial, computing, or consumer applications, the STL33N65M2 offers the performance and reliability that modern technology demands.
