74LVC1G126DCKR E4 Real Image 74LVC1G126DCKR E4 Real Image
Same model may have multiple batches, images only for reference.
74LVC1G126DCKR E4 Real Image 74LVC1G126DCKR E4 Real Image
74LVC1G126DCKR E4 Real Image 74LVC1G126DCKR E4 Real Image
Same model may have multiple batches, images only for reference.

74LVC1G126DCKR E4

Part No 74LVC1G126DCKR E4
Manufacturer Texas Instruments
Catalog Logic - Buffers, Drivers, Receivers, Transceivers
Description IC BUFF/DVR TRI-ST N-INV SC70-5 / Buffer/Line Driver 1-CH Non-Inverting 3-ST CMOS 5-Pin SC-70 T/R
Datasheet
74LVC1G126DCKR E4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Buffer, Non-Inverting
Number of Elements 1
Number of Bits per Element 1
Output Type Push-Pull
Current - Output High, Low 32mA, 32mA
Supply Voltage - Operating 1.65 V to 5.5 V
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SC-70-5
Win Source Part Number 198222-74LVC1G126DCKR E4
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name 74LVC1G126
Introduction Date November 01, 2009
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian 74LVC1G126DCKR E4 CAD Model

Description

74LVC1G126DCKR E4

The 74LVC1G126DCKR E4 is a single buffer/line driver with 3-state output, designed to operate on low voltage levels, making it ideal for portable and battery-powered devices.

  • Features:
    • Wide supply voltage range: 1.65V to 5.5V
    • High noise immunity
    • Very low power consumption
  • Applications:
    • Project designs involving portable devices
    • Signal buffering applications
    • Microcontroller-driven systems
  • Benefits:
    • Compact SOT-353 package for space-constrained designs
    • Enhanced performance for complex systems due to high noise immunity
    • Suitable for configurations operating at diverse voltage levels

    • This product is a versatile component for optimizing circuit design where power efficiency and reduced footprint are essential.
