CSD18504Q5A Real Image CSD18504Q5A real image3112 CSD18504Q5A real image3113 CSD18504Q5A Real Image
Same model may have multiple batches, images only for reference.
CSD18504Q5A Real Image CSD18504Q5A real image3112 CSD18504Q5A real image3113 CSD18504Q5A Real Image
CSD18504Q5A Real Image CSD18504Q5A real image3112 CSD18504Q5A real image3113 CSD18504Q5A Real Image
Same model may have multiple batches, images only for reference.

CSD18504Q5A

Part No CSD18504Q5A
Manufacturer Texas Instruments
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 8SON
Datasheet
CSD18504Q5A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 15A (Ta), 50A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.4V @ 250μA
Max Gate Charge 19nC @ 10V
Max Input Capacitance 1656pF @ 20V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3.1W (Ta), 77W (Tc)
Maximum Rds On at Id,Vgs 6.6 mOhm @ 17A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-VSON (5x6)
Dimension 8-PowerTDFN
Win Source Part Number 116747-CSD18504Q5A
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian CSD18504Q5A CAD Model

Description

Product Description

The CSD18504Q5A is a high-performance N-channel MOSFET with excellent power handling capabilities. It is designed to deliver superior electrical performance for various applications, making it a reliable choice for power management solutions.

Applications

  • DC-DC Converters
  • Battery Management Systems
  • Load Switches
  • Motor Drives

Features and Benefits

  • Low On-Resistance: Minimizes power loss and improves efficiency.
  • High-Speed Switching: Enhances performance in fast-switching applications.
  • Thermal Performance: Optimal thermal management for enhanced reliability.

Additional Details

Optimized for high-density power applications, the CSD18504Q5A is suited for both commercial and industrial environments, ensuring cost-effective and durable operations.
