LP2980IM5-3.3/NOPB Real Image LP2980IM5-3.3/NOPB real image LP2980IM5-3.3/NOPB label picture LP2980IM5-3.3/NOPB label picture 2
Same model may have multiple batches, images only for reference.
LP2980IM5-3.3/NOPB Real Image LP2980IM5-3.3/NOPB real image LP2980IM5-3.3/NOPB label picture LP2980IM5-3.3/NOPB label picture 2
LP2980IM5-3.3/NOPB Real Image LP2980IM5-3.3/NOPB real image LP2980IM5-3.3/NOPB label picture LP2980IM5-3.3/NOPB label picture 2
Same model may have multiple batches, images only for reference.

LP2980IM5-3.3/NOPB

Part No LP2980IM5-3.3/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 3.3V 50MA SOT23-5
Datasheet
LP2980IM5-3.3/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 16V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 0.22V @ 50mA
Output Current 50mA
Operating Supply Current 95μA to 1.2mA
PSRR 63dB (1kHz)
Control Features Enable
Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 0.12V @ 50mA
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 116119-LP2980IM5-3.3/NOPB
Family Name LP2980
Introduction Date April 01, 2000
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Consumer Electronics, Computers & Computer Peripherals, Power Management, Imaging, Video & Vision
Ultra Librarian 3D Model Ultra Librarian LP2980IM5-3.3/NOPB CAD Model

Description

The LP2980IM5-3.3/NOPB is a high-performance, low noise, micro-power voltage regulator from Texas Instruments, a leading global semiconductor company. This product is designed to meet the rigorous demands of contemporary electronic devices that require a stable and efficient power supply.

  • Fixed Output Voltage: 3.3V
  • Output Current: 50mA
  • Low Dropout Voltage: Beneficial for battery-operated devices
  • Low Quiescent Current: Enhances battery life in idle mode
  • Line and Load Regulation: Ensures stable output voltage under varying conditions
  • Package: SOT-23
  • Thermal Protection: Ensures safety and longevity of the device
  • High Power Supply Rejection Ratio (PSRR): Maintains stable output voltage even with input voltage variations
