SN74HC132DR Real Image SN74HC132DR real image5973 SN74HC132DR Real Image1 SN74HC132DR Real Image2 SN74HC132DR Real Image3 SN74HC132DR Real Image4 SN74HC132DR Real Image5
Same model may have multiple batches, images only for reference.
SN74HC132DR Real Image SN74HC132DR real image5973 SN74HC132DR Real Image1 SN74HC132DR Real Image2 SN74HC132DR Real Image3 SN74HC132DR Real Image4 SN74HC132DR Real Image5
SN74HC132DR Real Image SN74HC132DR real image5973 SN74HC132DR Real Image1 SN74HC132DR Real Image2 SN74HC132DR Real Image3 SN74HC132DR Real Image4 SN74HC132DR Real Image5
Same model may have multiple batches, images only for reference.

SN74HC132DR

Part No SN74HC132DR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE NAND 4CH 2-INP 14-SOIC
Datasheet
SN74HC132DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type NAND Gate
Number of Circuits 4
Number of Inputs 2
Features Schmitt Trigger
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 5.2mA, 5.2mA
Logic Level - Low 0.3 V to 1.2 V
Logic Level - High 1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL 21ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 006821-SN74HC132DR
Family Name SN74HC132
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SN74HC132DR CAD Model

Description

The SN74HC132DR is a high-performance, integrated circuit product from Texas Instruments, a renowned global semiconductor company that designs and manufactures analog ICs and embedded processors.

  • Function: Quadruple positive-NAND gate with Schmitt-trigger inputs
  • Series: SN74
  • Voltage Range: 2V to 6V
  • Inputs: Hysteresis (Schmitt-trigger)
  • Operating Temperature: -40°C to 85°C
  • Package: 14-pin small-outline integrated circuit (SOIC)
  • Compliance: RoHS compliant
