Product Overview: TL16C752BPTRG4 from Texas Instruments

The TL16C752BPTRG4 is a high-performance dual UART (Universal Asynchronous Receiver/Transmitter) integrated circuit from Texas Instruments, designed to meet the communication needs of embedded systems. This device offers enhanced features for industrial and commercial applications requiring reliable serial port expansions.

Key Features

• High Data Transfer Rate: Capable of baud rates up to 3 Mbps, the TL16C752BPTRG4 ensures swift data transmission for time-sensitive applications.
• Dual Channel: With two independent UART channels, it allows simultaneous communication with multiple peripherals, increasing system throughput and efficiency.
• 64-Byte FIFO Buffers: Each UART channel is equipped with 64-byte FIFOs to reduce the number of required interrupts and to assist in reliable data transfer.
• Auto Flow Control: It supports hardware and software flow control (XON/XOFF) to prevent data loss during transmission and reception.
• Programmable Baud Rate Generator: Flexibility in setting the baud rate is provided, which is essential for compatibility with various communication standards.
• Sleep and Power-Down Modes: Designed for power-sensitive applications, it includes low-power modes to conserve energy when the device is not actively communicating.
• Industrial Temperature Range: The device operates reliably across a broad temperature range, making it suitable for industrial environments.

Applications

The TL16C752BPTRG4 is ideal for applications that require high-speed serial data communication and robust performance. It is commonly used in point-of-sale systems, networking equipment, factory automation, and data acquisition systems. Its reliability and advanced features make it a preferred choice for designers who demand efficient and consistent serial communication.

Packaging and Quality

This device is available in a 48-TQFP (Thin Quad Flat Pack) package, ensuring a compact footprint for space-constrained applications. As a product of Texas Instruments, the TL16C752BPTRG4 adheres to high manufacturing standards, offering both performance and durability for your critical design requirements.
