TLV75801PDBVR - Texas Instruments Voltage Regulator

The TLV75801PDBVR from Texas Instruments is a highly efficient, low-dropout voltage regulator (LDO) designed to deliver a stable and reliable power supply to a wide range of applications. This compact LDO is an excellent choice for space-constrained and low-power systems, providing a fixed output voltage of 1.0V with an input voltage range of 2.5V to 6.0V.

Key Features:

• High Accuracy: The TLV75801PDBVR offers a 1% accuracy over line, load, and temperature variations, ensuring a consistent output for sensitive applications.
• Low Dropout: With a dropout voltage of just 100mV at 1A, this LDO can maintain regulation even when the supply voltage is close to the output voltage, which is especially useful in battery-operated devices.
• Current Capacity: It is capable of delivering up to 1A of continuous output current, making it suitable for powering a variety of ICs and embedded systems.
• Power-Saving Mode: The device features an innovative power-saving mode that significantly reduces quiescent current under light load conditions, thereby extending battery life in portable applications.
• Thermal Protection: Built-in thermal shutdown protection ensures that the device and the system it powers are safeguarded against overheating.
• Stability: The TLV75801PDBVR is stable with ceramic capacitors as low as 1µF, making it a versatile choice for different design requirements.

Applications:

This voltage regulator is ideal for a variety of applications, including but not limited to:

• Portable and battery-powered devices
• Wireless communication systems
• Power supply for microcontrollers and digital ICs
• Medical and healthcare equipment
• Automotive infotainment and telematics

Package and Availability:

The TLV75801PDBVR is available in a small 5-pin SOT-23 package, which is ideal for space-constrained applications. Its compact size, coupled with its robust feature set, makes it a preferred choice for designers looking for a reliable power management solution. For pricing, availability, and additional technical specifications, please visit the Texas Instruments website or contact an authorized distributor.
