The HN3C10FU is a silicon NPN epitaxial planar type transistor designed for RF amplification applications, manufactured by Toshiba Semiconductor and Storage. As a Bipolar Junction Transistor (BJT), it offers good gain and high-frequency performance suitable for use in various communication devices and high-frequency circuits.

Applications

• RF Amplifiers: Used in radio frequency amplifier circuits.
• Oscillators: Employed in oscillator circuits for signal generation.
• Mixers: Found in mixer stages to convert frequencies.
• Communication Equipment: Utilized in communication devices such as radio transceivers and wireless systems.

Features

• NPN Silicon Epitaxial Planar Transistor: Offers good performance and reliability.
• High Transition Frequency (fT): Typically exhibits a high transition frequency, enabling amplification at high frequencies.
• Low Noise Figure: Designed for low noise amplification, crucial in sensitive receiver applications.
• Small Package: Available in a compact package for space-saving designs.

Benefits

• Improved RF Performance: Enhances the performance of RF amplifier circuits.
• Compact Design: Allows for miniaturization of electronic devices due to its small package size.
• Reliable Operation: Provides stable and reliable operation in RF applications.
• Low Noise Amplification: Ensures minimal noise contribution in receiver circuits.

Specifications

While precise specifications can vary, key parameters typically include:

• Collector-Base Voltage (VCBO): e.g., 20 V
• Collector-Emitter Voltage (VCEO): e.g., 12 V
• Emitter-Base Voltage (VEBO): e.g., 3 V
• Collector Current (IC): e.g., 50 mA
• Transition Frequency (fT): e.g., 7 GHz
• Power Dissipation (PC): e.g., 200 mW

The HN3C10FU is commonly available in a small surface-mount package such as SOT-323, facilitating efficient board assembly and compact designs. It is an ideal choice for applications requiring high-frequency amplification with low noise and reliable performance.
