IRFI520GPBF Real Image IRFI520GPBF Real Image
Same model may have multiple batches, images only for reference.
IRFI520GPBF Real Image IRFI520GPBF Real Image
IRFI520GPBF Real Image IRFI520GPBF Real Image
Same model may have multiple batches, images only for reference.

IRFI520GPBF

Part No IRFI520GPBF
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 7.2A TO220FP
Datasheet
IRFI520GPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 7.2A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 16nC @ 10V
Max Input Capacitance 360pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 37W (Tc)
Maximum Rds On at Id,Vgs 270 mOhm @ 4.3A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220-3
Dimension TO-220-3 Full Pack, Isolated Tab
Win Source Part Number 135000-IRFI520GPBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRFI520GPBF CAD Model

Description

The IRFI520GPBF is a high power N-channel MOSFET transistor manufactured by Vishay.

  • Maximum Power Dissipation: 37W
  • Continuous Drain Current: 7.2A @ 25°C
  • Market Status: medium popularity with a limited supply and demand status
  • Common Usage: commonly used in power supplies, motor control, and lighting applications.
  • Breakdown Voltage: 100V
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Gate-Source Voltage: ±20V
  • Maximum Input Capacitance: 360pF @ 25V
  • Maximum On-Resistance: 270 mOhm @ 4.3A, 10V
