SI2309CDS-T1-GE3

Name: SI2309CDS-T1-GE3
Brand: Vishay
SKU: 321024
Availability: InStock
Rating: 4.91 (82 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SI2309CDS-T1-GE3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 60V 1.6A SOT23-3
Datasheet	SI2309CDS-T1-GE3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	60V
Continuous Drain Current at 25°C	1.6A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	3V @ 250μA
Max Gate Charge	4.1nC @ 4.5V
Max Input Capacitance	210pF @ 30V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	1W (Ta), 1.7W (Tc)
Maximum Rds On at Id,Vgs	345 mOhm @ 1.25A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-23-3 (TO-236)
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	028375-SI2309CDS-T1-GE3
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	Si2309CDS
Introduction Date	October 30, 2008
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Ultra Librarian 3D Model	Ultra Librarian SI2309CDS-T1-GE3 CAD Model

Alternative Products

Description

The Vishay Si2309CDS series MOSFET is a P-channel component with a package of SOT-23-3 (TO-236).

Breakdown Voltage: 60V
Continuous Drain Current: 1.6A (Tc)
Operating Temperature Range: -55°C to 150°C (TJ)
Application: Discrete Semiconductor Products
Supply: Reel with a quantity of 3000
Classification: EAR99
HTSUS: 8541.10.0050
Alternative Parts: ZXMP6A13F, ZXMP6A13FTA, and ZXMP6A13FQTA
