SI4204DY-T1-GE3 Real Image1 SI4204DY-T1-GE3 Real Image2 SI4204DY-T1-GE3 real image11037
Same model may have multiple batches, images only for reference.
SI4204DY-T1-GE3 Real Image1 SI4204DY-T1-GE3 Real Image2 SI4204DY-T1-GE3 real image11037
SI4204DY-T1-GE3 Real Image1 SI4204DY-T1-GE3 Real Image2 SI4204DY-T1-GE3 real image11037
Same model may have multiple batches, images only for reference.

SI4204DY-T1-GE3

Part No SI4204DY-T1-GE3
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2N-CH 20V 19.8A 8-SOIC
Datasheet
SI4204DY-T1-GE3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
FET Type 2 N-Channel (Dual)
FET Feature Standard
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 19.8A
Maximum Rds On at Id,Vgs 4.6 mOhm @ 10A, 10V
Gate-Source Threshold Voltage 2.4V @ 250μA
Max Gate Charge 45nC @ 10V
Max Input Capacitance 2110pF @ 10V
Maximum Power Dissipation 3.25W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 1095907-SI4204DY-T1-GE3
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Industrial, Power Management
Ultra Librarian 3D Model Ultra Librarian SI4204DY-T1-GE3 CAD Model

Description

The Vishay SI4204DY-T1-GE3 is a dual 2 N-Channel FET that is mounted in SMD (SMT) and comes in 8-SO package.

  • Manufacturer: Vishay
  • Maximum Power Dissipation: 3.25W
  • Continuous Drain Current: 19.8A @ 25°C
  • FET Feature: Standard
  • Drain-Source Breakdown Voltage: 20V
  • Gate-Source Threshold Voltage: 2.4V @ 250μA
  • Maximum Gate Charge: 45nC @ 10V
  • Maximum Rds On @ Id,Vgs: 4.6 mOhm @ 10A, 10V
  • Application: Industrial and Power Management
