AO4421 Real Image AO4421 real image AO4421 label picture AO4421 real image1847 AO4421 real image1848 AO4421 Real Image1 AO4421 Real Image2
Same model may have multiple batches, images only for reference.
AO4421 Real Image AO4421 real image AO4421 label picture AO4421 real image1847 AO4421 real image1848 AO4421 Real Image1 AO4421 Real Image2
AO4421 Real Image AO4421 real image AO4421 label picture AO4421 real image1847 AO4421 real image1848 AO4421 Real Image1 AO4421 Real Image2
Same model may have multiple batches, images only for reference.

AO4421

Part No AO4421
Manufacturer Alpha & Omega Semiconductor Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET P-CH 60V 6.2A 8-Pin SOIC / MOSFET P-CH 60V 6.2A 8SOIC
Datasheet
AO4421 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Alpha & Omega Semiconductor Inc.
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 6.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 55nC @ 10V
Max Input Capacitance 2900pF @ 30V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3.1W (Ta)
Maximum Rds On at Id,Vgs 40 mOhm @ 6.2A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Dimension 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 009745-AO4421
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name AO4421
Introduction Date September 24, 2004
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian AO4421 CAD Model

Description

AO4421: Energy-Efficient N-Channel MOSFET

The AO4421 provides an optimal balance between efficiency and power, suitable for power management and switching tasks. Its engineering excellence underpins its usage in various electronic components.

Features and Benefits

  • Optimized for low power dissipation
  • Fast response with high-speed switching
  • Durable under a wide range of temperatures
  • SMD packaging for modern design requirements

Applications

  • Consumer electronics
  • Automotive electronics
  • Power adapters
  • Electronic toys

Additional Details

This MOSFET offers a comprehensive solution to achieve energy-saving goals in modern electronic projects, ensuring dependable performance and reliability.
