Diodes Incorporated DMN2004DMK-7 N-Channel MOSFET

The DMN2004DMK-7 from Diodes Incorporated is a high-performance N-Channel enhancement mode Field Effect Transistor (MOSFET) designed for a wide range of applications. It utilizes advanced trench technology to provide excellent RDS(on) and low gate charge. This MOSFET is a part of Diodes Incorporated's extensive portfolio of semiconductor solutions, known for their reliability and efficiency.

With its small footprint, the DMN2004DMK-7 is housed in a compact SOT-26 package, making it ideal for space-constrained applications. It operates with a drain-source voltage (Vds) of 20V, and can handle a continuous drain current (Id) of up to 0.54A at a temperature of 25°C. This makes it suitable for high-density circuit designs where power efficiency is critical.

The DMN2004DMK-7 features a low threshold voltage (Vgs(th)) that ensures low voltage operation, which is beneficial for portable electronics that require minimal power consumption. The low input capacitance and low on-resistance (RDS(on)) contribute to its high efficiency, reducing power losses and improving overall system performance.

Applications for the DMN2004DMK-7 are diverse and include load switch circuits, power management in portable and battery-powered devices, DC-DC converters, and other switching applications where power efficiency is paramount. Its fast switching speed also makes it suitable for high-frequency circuits.

Key features of the DMN2004DMK-7 include:

• Drain-Source Voltage (Vds): 20V
• Continuous Drain Current (Id): 0.54A
• Low On-Resistance (RDS(on))
• Low Input Capacitance
• Fast Switching Speed
• High Power and Current Handling Capability
• RoHS Compliant

Diodes Incorporated's commitment to quality ensures that the DMN2004DMK-7 MOSFET meets the stringent requirements of the electronics industry. Its robust design and reliability make it an excellent choice for designers looking to optimize their power management systems.
