FCPF16N60NT Real Image FCPF16N60NT real image
Same model may have multiple batches, images only for reference.
FCPF16N60NT Real Image FCPF16N60NT real image
FCPF16N60NT Real Image FCPF16N60NT real image
Same model may have multiple batches, images only for reference.

FCPF16N60NT

Part No FCPF16N60NT
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 600V TO-220-3
Datasheet
FCPF16N60NT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 600V
Continuous Drain Current at 25°C 16A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 52.3nC @ 10V
Max Input Capacitance 2170pF @ 100V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 35.7W (Tc)
Maximum Rds On at Id,Vgs 199 mOhm @ 8A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-220F-3
Dimension TO-220-3 Full Pack
Win Source Part Number 066895-FCPF16N60NT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian FCPF16N60NT CAD Model

Description

FCPF16N60NT MOSFET Transistor

Manufactured for precision, the FCPF16N60NT MOSFET transistor provides high-speed operation ideal for energy-efficient designs. It is widely applicable in high-efficiency power management systems.

  • Telecommunication power supplies
  • Power adapters
  • Renewable energy converters
  • Charger applications

Features and Benefits

  • Optimal on-state efficiency
  • High-frequency switching capability
  • Consistent thermal performance

Additional Details: Focused on energy conservation, this component reduces electricity consumption and supports sustainable power management solutions.
