FDD8447L_F085 Real Image FDD8447L_F085 label picture
Same model may have multiple batches, images only for reference.
FDD8447L_F085 Real Image FDD8447L_F085 label picture
FDD8447L_F085 Real Image FDD8447L_F085 label picture
Same model may have multiple batches, images only for reference.

FDD8447L_F085

Part No FDD8447L_F085
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 50A DPAK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 50A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 3V @ 250μA
Max Gate Charge 52nC @ 10V
Max Input Capacitance 1970pF @ 20V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 65W (Tc)
Maximum Rds On at Id,Vgs 8.5 mOhm @ 14A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-PAK (TO-252AA)
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 121874-FDD8447L_F085
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian FDD8447L_F085 CAD Model

Description

The FDD8447L_F085 is an enhanced variant of the FDD8447L MOSFET, meticulously crafted to operate efficiently across a broader range of temperatures. This makes it ideal for automotive and industrial applications that demand high reliability in harsh environments.

Features and Benefits

  • Extended temperature range ensures reliability in extreme conditions
  • Low on-state resistance similar to FDD8447L, ensuring energy efficiency
  • Automotive-grade quality for superior standards of performance

Applications

  • Automotive electronics
  • Industrial motor control systems
  • Power supplies and converters

With the FDD8447L_F085, designers are well-equipped to handle power systems reliably, even at extreme temperatures.
