FJC1963STF Real Image FJC1963STF real image FJC1963STF label picture
Same model may have multiple batches, images only for reference.
FJC1963STF Real Image FJC1963STF real image FJC1963STF label picture
FJC1963STF Real Image FJC1963STF real image FJC1963STF label picture
Same model may have multiple batches, images only for reference.

FJC1963STF

Part No FJC1963STF
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS NPN 30V 3A SOT-89 / Trans GP BJT NPN 30V 3A 4-Pin(3+Tab) SOT-89 T/R
Datasheet
FJC1963STF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel package
Part Status Obsolete(EOL)
Transistor Type NPN
Current - Collector (Ic) (Maximum) 3A
Voltage - Collector Emitter Breakdown (Maximum) 30V
Vce Saturation (Maximum) @ Ib, Ic 450mV @ 150mA, 1.5A
Current - Collector Cutoff (Maximum) 500nA
DC Current Gain (hFE) (Minimum) @ Ic, Vce 280 @ 500mA, 2V
Power - Max 500mW
Operating Temperature Range 150°C (TJ)
Mounting SMD
Package TO-243AA
Manufacturer Package SOT-89-3
Win Source Part Number 774590-FJC1963STF
Popularity Medium
Supply and Demand Status Limited
Family Name FJC1963S
Introduction Date July 05, 2001
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian FJC1963STF CAD Model

Description

The FJC1963STF is an obsolete NPN transistor manufactured by Fairchild/ON Semiconductor.

  • Package: TO-243AA
  • Maximum Power: 500mW
  • Current - Collector (Ic) (Maximum): 3A
  • Voltage - Collector Emitter Breakdown (Maximum): 30V
  • Vce Saturation (Maximum) @ Ib, Ic: 450mV @ 150mA, 1.5A
  • DC Current Gain (hFE) (minimum) @ Ic, Vce: 280 @ 500mA, 2V
  • Current - Collector Cutoff (Maximum): 500nA
  • Category: discrete semiconductor products
  • Manufacturer Package: SOT-89-3
  • Status: obsolete/end of life
  • Supply and Demand Status: limited
