FQPF27P06 Real Image FQPF27P06 Real Image
Same model may have multiple batches, images only for reference.
FQPF27P06 Real Image FQPF27P06 Real Image
FQPF27P06 Real Image FQPF27P06 Real Image
Same model may have multiple batches, images only for reference.

FQPF27P06

Part No FQPF27P06
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 60V 17A TO-220F
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 17A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 43nC @ 10V
Max Input Capacitance 1400pF @ 25V
Maximum Gate-Source Voltage ±25V
Power Dissipation (Max) 47W (Tc)
Maximum Rds On at Id,Vgs 70 mOhm @ 8.5A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220F
Dimension TO-220-3 Full Pack
Win Source Part Number 204310-FQPF27P06
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Power Management, Lighting, Motor Drive & Control, Audio
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian FQPF27P06 CAD Model

Description

The Fairchild/ON Semiconductor 204310-FQPF27P06 is a P-channel MOSFET.

  • Applications: Power management, lighting, motor drive & control, and audio
  • Rds on (max): 70 mOhm @ 8.5A, 10V
  • Drain-Source Breakdown Voltage: 60V
  • Maximum Gate-Source Voltage: ±25V
  • Maximum Gate Charge: 43nC @ 10V
  • Operating Temperature Range: -55°C to 175°C (TJ)
  • Packaging: Tube/Rail
  • Supply and Demand Status: Limited
  • Package Quantity: 1k pcs
