KA78R05CTU Real Image KA78R05CTU Real Image
Same model may have multiple batches, images only for reference.
KA78R05CTU Real Image KA78R05CTU Real Image
KA78R05CTU Real Image KA78R05CTU Real Image
Same model may have multiple batches, images only for reference.

KA78R05CTU

Part No KA78R05CTU
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Regulators - Linear
Description LDO Regulator Pos 5V 1A 4-Pin(4+Tab) TO-220F Tube / IC REG LDO 5V 1A TO220F-4
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 35V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 0.5V @ 1A
Output Current 1A
Operating Supply Current 10mA
Control Features Enable
Protection Features Over Current, Over Temperature, Over Voltage, Short Circuit
Temperature Range - Operating -20°C to 80°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 0.5V @ 1A
Mounting Through Hole
Case / Package TO-220F-4L
Win Source Part Number 018200-KA78R05CTU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial, Power Management
Quantity per package 1k pcs
Family Name KA78R05C
Introduction Date August 26, 2003
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2021
Ultra Librarian 3D Model Ultra Librarian KA78R05CTU CAD Model

Description

The Fairchild/ON Semiconductor KA78R05CTU is a positive fixed voltage regulator that is designed to provide a stable 5V output voltage with a dropout voltage of just 0.5V @ 1A.

  • Maximum Input Voltage: 35V
  • Nominal Output Voltage: 5V
  • Mounting: Through-hole
  • Package: TO-220F-4L
  • Output Current: 1A
  • Operating Supply Current: 10mA (low)
  • Protection: Over-current, over-temperature, over-voltage, and short-circuit
