MBRB3060CT Sangdest Microelectronic (Nanjing) Co., Ltd
Same model may have multiple batches, images only for reference.

MBRB3060CT

Part No MBRB3060CT
Manufacturer GOOD-ARK Electronics
Catalog Diodes, Rectifiers - Arrays
Description RECTIFIER, SCHOTTKY, 30A, 60V, T
Datasheet
MBRB3060CT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr GOOD-ARK Electronics
Package Tape & Reel
Product Status Active
Diode Configuration 1 Pair Common Cathode
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 60 V
Current - Average Rectified (Io) (per Diode) 30mA
Voltage - Forward (Vf) (Max) @ If 780 mV @ 30 mA
Speed Small Signal =< 200mA (Io), Any Speed
Current - Reverse Leakage @ Vr 200 nA @ 60 V
Operating Temperature - Junction -55°C ~ 150°C
Mounting Type Surface Mount
Package / Case TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Supplier Device Package TO-263
Standard Package 800 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 633595-MBRB3060CT
Ultra Librarian 3D Model Ultra Librarian MBRB3060CT CAD Model

Description

The GOOD-ARK Electronics diode array with the part number 633595-MBRB3060CT is a high-quality electronic component in the category of discrete semiconductor products.

  • Package: tape and reel
  • Quantity: 800 pieces
  • Product Status: active
  • REACH Regulations: unaffected
  • Speed: small signal
  • Current: less than 200mA
  • Technology: Schottky
  • Maximum Reverse Voltage: 60V
  • Forward Voltage Drop: 780mV @ 30mA
  • Mounting: surface mountable
  • Applications: power supplies, rectifiers, and other electronic devices
  • Manufacturer: GOOD-ARK Electronics
