Same model may have multiple batches, images only for reference.
IPW60R230P6FKSA1 Infineon Technologies
Same model may have multiple batches, images only for reference.

IPW60R230P6FKSA1

Part No IPW60R230P6FKSA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 600V 16.8A TO247-3 / N-Channel 600 V 16.8A (Tc) 126W (Tc) Through Hole PG-TO247-3
Datasheet
IPW60R230P6FKSA1 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr Infineon Technologies
Series CoolMOS™ P6
Package Tube
Product Status Obsolete
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 600 V
Current - Continuous Drain (Id) @ 25°C 16.8A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 230mOhm @ 6.4A, 10V
Vgs(th) (Max) @ Id 4.5V @ 530µA
Gate Charge (Qg) (Max) @ Vgs 31 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 1450 pF @ 100 V
Power Dissipation (Max) 126W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Supplier Device Package PG-TO247-3
Package / Case TO-247-3
Base Product Number IPW60R
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Names SP001017088,2156-IPW60R230P6FKSA1-IT,IFEINFIPW60R230P6FKSA1
Standard Package 240
Win Source Part Number 1028134-IPW60R230P6FKSA1
Ultra Librarian 3D Model Ultra Librarian IPW60R230P6FKSA1 CAD Model

Description

The Infineon Technologies 1028134-IPW60R230P6FKSA1 is an N-channel MOSFET transistor from the CoolMOS™ P6 series.

  • Manufacturer: Infineon Technologies
  • Product Name: 1028134-IPW60R230P6FKSA1
  • Type: N-channel MOSFET transistor
  • Series: CoolMOS™ P6
  • Applications: Power supplies, motor control, and lighting.
  • Drain to Source Voltage: 600V
  • Continuous Drain Current: 16.8A (Tc)
  • Maximum On-Resistance: 230mOhm @ 6.4A and 10V
  • Gate Threshold Voltage: 4.5V @ 530μA
  • Package: Through-hole
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Lifecycle Status: Obsolete
  • Recommendation: Consult with authorized distributors for a suitable replacement.
