IRF3808PBF real image245
Same model may have multiple batches, images only for reference.

IRF3808PBF

Part No IRF3808PBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 75V 140A TO-220AB
Datasheet
IRF3808PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 75V
Continuous Drain Current at 25°C 140A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 220nC @ 10V
Max Input Capacitance 5310pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 330W (Tc)
Maximum Rds On at Id,Vgs 7 mOhm @ 82A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 017428-IRF3808PBF
Family Name IRF3808
Introduction Date February 02, 2004
ECCN EAR99
Country of Origin China, Philippines
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRF3808PBF CAD Model

Description

The Infineon Technologies IRF3808PBF is an N-channel MOSFET transistor suitable for use in high power applications.

  • Drain-Source Breakdown Voltage: 75V
  • Maximum Continuous Drain Current @ 25°C: 140A @ 25°C
  • On-Resistance: 7 mOhm @ 82A and 10V
  • Gate Charge: 220nC @ 10V
  • Input Capacitance: 5310pF @ 25V
