IRF7307TRPBF Infineon Technologies IRF7307TRPBF real image271
Same model may have multiple batches, images only for reference.
IRF7307TRPBF Infineon Technologies IRF7307TRPBF real image271
IRF7307TRPBF Infineon Technologies IRF7307TRPBF real image271
Same model may have multiple batches, images only for reference.

IRF7307TRPBF

Part No IRF7307TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N/P-CH 20V 8-SOIC
Datasheet
IRF7307TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
FET Type N and P-Channel
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 5.2A, 4.3A
Maximum Rds On at Id,Vgs 50 mOhm @ 2.6A, 4.5V
Gate-Source Threshold Voltage 700mV @ 250μA
Max Gate Charge 20nC @ 4.5V
Max Input Capacitance 660pF @ 15V
Maximum Power Dissipation 2W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 109378-IRF7307TRPBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRF7307TRPBF CAD Model

Description

The Infineon Technologies IRF7307TRPBF is an N and P-Channel MOSFET transistor that features a logic level gate.

  • Maximum Power Dissipation: 2W
  • Drain-Source Breakdown Voltage: 20V
  • Continuous Drain Current at 25°C: 5.2A, 4.3A
  • Gate-Source Threshold Voltage: 700mV @ 250μA
  • Maximum Gate Charge: 20nC @ 4.5V
  • Maximum Rds On at Id,Vgs: 50 mOhm @ 2.6A, 4.5V
  • Widely Used: Discrete Semiconductor Products
  • Status: active part
  • Supply and Demand Status: limited
