IRF7324TRPBF Infineon Technologies IRF7324TRPBF real image274 IRF7324TRPBF Real Image1 IRF7324TRPBF Real Image2
Same model may have multiple batches, images only for reference.
IRF7324TRPBF Infineon Technologies IRF7324TRPBF real image274 IRF7324TRPBF Real Image1 IRF7324TRPBF Real Image2
IRF7324TRPBF Infineon Technologies IRF7324TRPBF real image274 IRF7324TRPBF Real Image1 IRF7324TRPBF Real Image2
Same model may have multiple batches, images only for reference.

IRF7324TRPBF

Part No IRF7324TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2P-CH 20V 9A 8-SOIC
Datasheet
IRF7324TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
FET Type 2 P-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 9A
Maximum Rds On at Id,Vgs 18 mOhm @ 9A, 4.5V
Gate-Source Threshold Voltage 1V @ 250μA
Max Gate Charge 63nC @ 5V
Max Input Capacitance 2940pF @ 15V
Maximum Power Dissipation 2W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 017505-IRF7324TRPBF
Family Name IRF7324
Introduction Date March 29, 2001
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRF7324TRPBF CAD Model

Description

The Infineon Technologies IRF7324TRPBF is a P-Channel (Dual) FET Type that is designed for use in various circuits.

  • Category: Discrete Semiconductor Products
  • Supply and Demand Status: Limited
  • Mounting: Surface-mounted using SMD (SMT) technology
  • Packaging: Reels
  • Operating Temperature: -55°C to 150°C
  • Maximum Power Dissipation: 2W
  • ECCN: EAR99
  • HTSUS Code: Not specified
  • Package Contains: 1 unit
