IRFU9N20D Infineon Technologies IRFU9N20D label picture IRFU9N20D real image
Same model may have multiple batches, images only for reference.
IRFU9N20D Infineon Technologies IRFU9N20D label picture IRFU9N20D real image
IRFU9N20D Infineon Technologies IRFU9N20D label picture IRFU9N20D real image
Same model may have multiple batches, images only for reference.

IRFU9N20D

Part No IRFU9N20D
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 200V 9.4A I-PAK
Datasheet
IRFU9N20D Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 200V
Continuous Drain Current at 25°C 9.4A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5.5V @ 250μA
Max Gate Charge 27nC @ 10V
Max Input Capacitance 560pF @ 25V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 86W (Tc)
Maximum Rds On at Id,Vgs 380 mOhm @ 5.6A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package IPAK (TO-251)
Dimension TO-251-3 Short Leads, IPak, TO-251AA
Win Source Part Number 1040393-IRFU9N20D
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRFU9N20D CAD Model

Description

The Infineon Technologies IRFU9N20D is a N-Channel MOSFET designed for use in various electronic circuits.

  • Polarity: N-Channel
  • Drain-Source Breakdown Voltage: 200V
  • Continuous Drain Current (at 25°C): 9.4A
  • Gate-Source Threshold Voltage: 5.5V @ 250μA
  • Gate Charge (Max): 27nC @ 10V
  • Input Capacitance (Max): 560pF @ 25V
  • Rds On (Max) at Id, Vgs: 380 mOhm @ 5.6A, 10V
  • Package: IPAK (TO-251)
  • Mounting Type: Through-Hole
  • Applications: Power Supplies, Motor Control Circuits
