Same model may have multiple batches, images only for reference.

IRLR8729TRPBF

Name: IRLR8729TRPBF
Brand: Infineon Technologies
SKU: 161648
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRLR8729TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 30V 58A DPAK
Datasheet	IRLR8729TRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	58A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	2.35V @ 25μA
Max Gate Charge	16nC @ 4.5V
Max Input Capacitance	1350pF @ 15V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	55W (Tc)
Maximum Rds On at Id,Vgs	8.9 mOhm @ 25A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	D-Pak
Dimension	TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number	017811-IRLR8729TRPBF
Family Name	IRLR8729
Introduction Date	December 16, 2008
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian IRLR8729TRPBF CAD Model

Alternative Products

Description

The Infineon Technologies IRLR8729TRPBF is a MOSFET transistor with an N-Channel polarity.

Supply and Demand Status: Limited
Maximum Rds On: 8.9 mOhm @ 25A, 10V
Maximum Gate-Source Voltage: ±20V
Halogen-Free: Yes
Estimated EOL Date: 2024

This transistor is widely used in discrete semiconductor products.
