ISL99140IRZ-T Real Image ISL99140IRZ-T real image
Same model may have multiple batches, images only for reference.
ISL99140IRZ-T Real Image ISL99140IRZ-T real image
ISL99140IRZ-T Real Image ISL99140IRZ-T real image
Same model may have multiple batches, images only for reference.

ISL99140IRZ-T

Part No ISL99140IRZ-T
Manufacturer Intersil
Catalog PMIC - Full, Half - Bridge Drivers
Description IC PWR MODULE DRMOS 40A 40QFN
Datasheet
ISL99140IRZ-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Reel - TR
Status Active
Applications DC-DC Converters
Load Type Inductive
Technology DrMOS
Channel Output Current 40A
Supply Voltage - Operating 4.75 V to 5.25 V
Voltage - Load 4.5 V to 18 V
Temperature Range - Operating -40°C to 125°C (TJ)
Features Bootstrap Circuit, Diode Emulation, Status Flag
Fault Protection Over Temperature, Shoot-Through, UVLO
Mounting SMD (SMT)
Case / Package 40-QFN (6x6)
Win Source Part Number 1049026-ISL99140IRZ-T
Family Name ISL99140
Introduction Date May 05, 2014
ECCN EAR99
Country of Origin China
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ISL99140IRZ-T CAD Model

Description

The supply and demand status is balanced for this component.

  • Technology: DrMOS
  • Type: DC-DC Converter
  • Channel Output Current: 40A
  • Load Type: Inductive
  • Voltage Load Range: 4.5V to 18V
  • Fault Protection: Over-Temperature, Shoot-Through, and UVLO
  • Features: Bootstrap Circuit, Diode Emulation, Status Flag
  • Packaging: 40-QFN (6x6)
  • Operating Temperature: -40°C to 125°C (TJ)
  • Estimated EOL Date: 2023
