IXTA3N120TRL Real Image IXTA3N120TRL label picture IXTA3N120TRL real image IXTA3N120TRL real image 2 IXTA3N120TRL Real Image1 IXTA3N120TRL Real Image2
Same model may have multiple batches, images only for reference.
IXTA3N120TRL Real Image IXTA3N120TRL label picture IXTA3N120TRL real image IXTA3N120TRL real image 2 IXTA3N120TRL Real Image1 IXTA3N120TRL Real Image2
IXTA3N120TRL Real Image IXTA3N120TRL label picture IXTA3N120TRL real image IXTA3N120TRL real image 2 IXTA3N120TRL Real Image1 IXTA3N120TRL Real Image2
Same model may have multiple batches, images only for reference.

IXTA3N120TRL

Part No IXTA3N120TRL
Manufacturer IXYS
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 1200V 3A TO-263
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer IXYS
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 1200V
Continuous Drain Current at 25°C 3A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5V @ 250μA
Max Gate Charge 42nC @ 10V
Max Input Capacitance 1350pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 200W (Tc)
Maximum Rds On at Id,Vgs 4.5 Ohm @ 1.5A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package TO-263 (IXTA)
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 1049735-IXTA3N120TRL
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IXTA3N120TRL CAD Model

Description

The IXTA3N120TRL is an N-Channel MOSFET transistor with a drain-source breakdown voltage of 1200V and a continuous drain current of 3A (Tc).

  • Drain-Source Breakdown Voltage: 1200V
  • Continuous Drain Current: 3A (Tc)
  • Gate-Source Threshold Voltage: 5V @ 250μA
  • Maximum Gate Charge: 42nC @ 10V
  • Technology: MOSFET
  • Package/Case: TO-263 (IXTA)
  • Application: Discrete Semiconductor Products
  • Power Dissipation: 200W (Tc)
