NES-50-24 Mean Well Enterprises Co., Ltd.
Same model may have multiple batches, images only for reference.

NES-50-24

Part No NES-50-24
Manufacturer Mean Well Enterprises Co., Ltd.
Catalog External/Internal (Off - Board) AC DC Converters
Description AC/DC CONVERTER 24V 53W / Enclosed AC DC Converters 1 Output 24V 85 ~ 264 VAC, 120 ~ 370 VDC Input
Datasheet
NES-50-24 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - External/Internal (Off-Board) - AC DC Converters
Mfr Mean Well Enterprises Co., Ltd.
Series NES-50 (50W)
Package Box
Product Status Obsolete
Type Enclosed
Number of Outputs 1
Voltage - Input 85 ~ 264 VAC, 120 ~ 370 VDC
Voltage - Output 1 24V
Current - Output 1 2.2 A
Power (Watts) 53W
Applications ITE (Commercial)
Voltage - Isolation 3 kV
Efficiency 86%
Temperature Range - Operating -20°C ~ 60°C (With Derating)
Features Adjustable Output, Universal Input
Mounting Type Chassis Mount
Size / Dimension 5.08" L x 3.86" W x 1.50" H (129.0mm x 98.0mm x 38.0mm)
Approval Agency CB, CCC, cURus
Minimum Load Required No
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9520
Win Source Part Number 648395-NES-50-24
Ultra Librarian 3D Model Ultra Librarian NES-50-24 CAD Model

Description

The NES-50-24 is a 50W AC/DC converter from Mean Well Enterprises Co., Ltd. The NES-50-24 has a package size of 5.08" L x 3.86" W x 1.50" H (129.0mm x 98.0mm x 38.0mm) and provides a single output with a voltage of 24V and a current output of 2.2A.

  • Manufacturer: Mean Well Enterprises Co., Ltd.
  • Series: NES-50
  • Type: Enclosed, Adjustable Output
  • Application: ITE (Commercial)
  • Power Output: 53W
  • Package Size: 5.08" L x 3.86" W x 1.50" H (129.0mm x 98.0mm x 38.0mm)
  • Output: Single
  • Voltage: 24V
  • Current Output: 2.2A
  • Efficiency: 86%
  • Voltage Isolation: 3 kV
  • Operating Temperature: -20°C to 60°C (with derating)
  • Approvals: CB, CCC, cURus
  • Status: Obsolete
