TCD-18-4X+

Part No TCD-18-4X+
Manufacturer Mini-Circuits
Catalog RF Directional Coupler
Description RF DIR COUPLER 5MHZ-1GHZ 6SMD
Datasheet
TCD-18-4X+ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Directional Coupler
Mfr Mini-Circuits
Package Tape & Reel
Product Status Active
Coupler Type Standard
Frequency 5MHz ~ 1GHz
Coupling Factor 17.9 ± 0.5dB
Applications General Purpose
Power - Max 1W
Return Loss 28.17dB
Package / Case 6-SMD, Flat Leads
Standard Package 2,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 936242-TCD-18-4X+
Ultra Librarian 3D Model Ultra Librarian TCD-18-4X+ CAD Model

Description

The 936242-TCD-18-4X+ is an RF directional coupler designed for general-purpose applications.

  • Frequency Range: 5MHz to 1GHz
  • Coupling Factor: 17.9 ± 0.5dB
  • Return Loss: 28.17dB
  • Maximum Power Rating: 1W
  • Package: 6-SMD, Flat Leads package
  • Product Status: active
  • Manufacturer: Mini-Circuits
